SCHEGO® HEATERS AND CONTROLLERS –
RELY ON A SAFE CONNECTION
RELY ON A SAFE CONNECTION
HEATERS, PTC-HEATERS AND CONTROLLER
Whenever liquids have to be heated the Schego heaters can be applied. They are made of high-quality titanium tube, therefore unbreakable and sea water-proof. All heating elements are grounded and guarantee a high safety standard. Their power range extends from 50 to 600 W. The heaters are used for laboratory baths and bacterial growths as well as in anti-freezing devices, mobile water heating systems and mobile hand-washing facilities
The novel PTC heaters made of titanium tubing are particularly energy-efficient because their output depends on the heat extraction. If a lot of heat is extracted from the heater, it readjusts its temperature independently and increases its output. As soon as it reaches its maximum temperature, the power decreases again and hardly any current flows. Thanks to this self-regulating property, PTC heaters cannot overheat, which makes them particularly safe.
Whenever a certain temperature should be reached and maintained the Schego thermostat TR2 is applied. It can be loaded up to 2000 W. Its LC display shows the operating parameter, the measuring range extends from – 55 °C to + 125 °C . Indexing accuracy can be chosen from 0.1 °C to 10.0° C in steps of 0.1 °C. The display is rotatable by 180° via keys. The TR2 is able to regulate cooling as well as heating devices reliably.
| art. no. | power consumption | length | Ø |
| 537 | 50 W | 250 mm | 25 mm |
| 539 | 75 W | 250 mm | 25 mm |
| 542 | 100 W | 250 mm | 25 mm |
| 544 | 150 W | 250 mm | 25 mm |
| 546 | 200 W | 250 mm | 25 mm |
| 547 | 250 W | 250 mm | 25 mm |
| 548 | 300 W | 250 mm | 25 mm |
| 560 | 600 W | 350 mm | 25 mm |
1,50m cable
Protection class IP 68
Further modifications regarding power supply, cable etc. on inquiry.
Reserve technical changes.
| art.-no. | power consumption (at 20° C) | length | Ø |
| 501 | 100 W | 150 mm | 12 mm |
| 502 | 200 W | 250 mm | 12 mm |
| 503 | 300 W | 350 mm | 12 mm |
| 506 | 600 W | 550 mm | 12 mm |
1,50 m cable
Protection class IP 68
Reserve technical changes.
thermostat TR2: art.no. 113
power supply: 220-240 V/50 Hz
sensor cable: 2 m
measuring range: – 55 to + 125 °C
accuracy: (adjustable) 0,1 to 10,0 °C
switching capacity: max. 2000 W
case: 60 x 98 x 40 mm
adjustable to heating and cooling
sensor monitoring for short circuit or interruption
LC display for temperature setting, socket (relay) on, sensor error, heating, cooling
display rotatable by 180° via keys
storage of the programmed switching waves even in the event of a power failure
Reserve technical changes.
