AQUARIUM TECHNOLOGY

Air for life: membrane pumps

Life in the aquarium is inconceivable without oxygen. Apart from further prerequisites such as heat and light, Schego membrane pumps contribute decisively to an aquarium becoming a habitat. Air is life.

Oxygen is vitally necessary for fish and primitive sea species in the aquarium, for they have no CO2 respiration. Leading experts also recommend oxygen as remedy for the regeneration of diseased fish. Nevertheless, pure oxygen should not be provided as this can act toxically. Schego offers membrane pumps for aeration or use in filter systems and protein skimmers. This guarantees keeping the animals in a species-appropriate environment in the aquarium.
All Schego membrane pumps work extremely reliably in continuous operation and are characterized by very quiet running, they have little vibration and are stable. Thanks to more than 70 years experience, high-quality and careful processing are a matter of course – naturally ”Made in Germany”.
Different performance types with an air delivery of 100 l/h to 350 l/h are available. Long-life
membranes, easily changeable prefilters, transparent housing with suspension are additional plus points with all Schego membrane pumps.

Air for life – everywhere
Membrane pumps for battery connection 12 V DC

Schego pumps for battery connection enable a supply of oxygen where no mains power is available.

These pumps have been developed for fish and live foods transport. Fish suffer from lack of oxygen during long lasting transports, especially in the summer months, so that the tanks must be aerated. Connecting the air pump to the car battery or to the cigarette lighter is suitable in this case. Therefore the approved 12 V pumps are available with a mounted car battery plug.
In recent years power supply by means of solar cells, especially in the leisure area, has become increasingly popular. Schego pumps in combination with solar cells are very well suited for this application and have proved their worth.

prima

art. no. 730
100 l/h
3 Watt
116 x 66 x 51 mm
1 m cable with Euro plug

Further modifications regarding power supply, cable version etc. on inquiry.
Reserve technical changes.

ideal

art. no. 769
150 l/h
5 Watt
130 x 70 x 50 mm
1 m cable with Euro plug

Further modifications regarding power supply, cable version etc. on inquiry.
Reserve technical changes.

optimal

art. no. 850
250 l/h
5 Watt
130 x 70 x 50 mm
1 m cable with Euro plug
with regulation

Further modifications regarding power supply, cable version etc. on inquiry.
Reserve technical changes.

WS2

art. no. 920
250 l/h
5 Watt
130 x 70 x 50 mm
1 m cable with Euro plug
with regulation
for 2 m water column

Further modifications regarding power supply, cable version etc. on inquiry.
Reserve technical changes.

M2K3

art. no. 739
350 l/h
5 Watt
160 x 75 x 60 mm
1 m cable with Euro plug
with regulation

Further modifications regarding power supply, cable version etc. on inquiry.
Reserve technical changes.

WS3

art. no. 930
350 l/h
7 Watt
160 x 75 x 60 mm
1 m cable with Euro plug
with regulation
for 3 m water column

Further modifications regarding power supply, cable version etc. on inquiry.
Reserve technical changes.

optimal electronic

art. no. 830
150 l/h
400 mA
130 x 70 x 50 mm
1 m cable without plug

Reserve technical changes.

optimal electronic

art. no. 830UB
150 l/h
400 mA
130 x 70 x 50 mm
1 m cable with car battery plug

Reserve technical changes.

TR extra electronic

art. no. 820
180 l/h
380 mA
153 x 75 x 82 mm
1 m cable without plug

Reserve technical changes.

TR extra electronic

art. no. 820UB
180 l/h
380 mA
153 x 75 x 82 mm
1 m cable with car battery plug

Reserve technical changes.

M2K3 electronic

art. no. 800
260 l/h
600 mA
160 x 75 x 60 mm
1 m cable without plug

Reserve technical changes.

M2K3 electronic

art. no. 800UB
260 l/h
600 mA
160 x 75 x 60 mm
1 m cable with car battery plug

Reserve technical changes.
